RAVI INTERNATIONAL (watch video) Syrup Manufacturing Plant consists the following equipment and accessories.
Sugar Syrup Vessel / Online Sugar Syrup Prefilter / Manufacturing Vessel / Filtration unit (Sparkler type Filter Press) / Inline Homogenizer (Micronizer) / Storage Vessel / Control Panel / Product Piping / Working Platform
Syrup Manufacturing Plant
The Liquid manufacturing plant is a set of equipment designed for the manufacture of syrups, liquid oral formulations and other water based pharmaceutical products for capacities ranging from 500 ltrs. to 10000 ltrs.
Sugar Dissolving Vessel:
The Sugar Dissolving Vessel is a jacketed cylindrical tank with torrispherical dish ends. A propeller type stirrer is provided for agitating the liquid.
Pre-Filter:
The Sugar Pre Filter is a small tank that contains a mesh, through which the sugar syrup is filtered before being transferred into the manufacturing vessel.
Manufacturing Vessel:
The Manufacturing Vessel is a jacketed cylindrical vessel with torrispherical dish ends and propeller type agitator. The vessel can be provided with a top stirrer or a bottom stirrer arrangement as per customer requirement.
Homogenizer:
The Tank Bottom Homogenizer or Inline mixer cum Micronizer is used with the manufacturing vessel to reduce particle size and promote uniform mixing.
Storage Vessel:
The Storage Vessel is a cylindrical tank with torrispherical dish ends in which the product may be collected and stored till it has to be transferred to the filling line. It is provided with a propeller type stirrer.
Transfer Pumps:
Two transfer pumps (twin lobe or centrifugal) are used; one to transfer the product from the Manufacturing Vessel to the Storage vessel and another to transfer the product from the Storage Vessel to the filling line.
Vacuum System:
The Vacuum System consists of a vacuum pump and inter-connecting pipeline. It is used for the transfer of sugar and sugar syrup.
Inter-Connecting Pipeline:
The Inter-Connecting Pipeline is provided for the plant as per the layout. All pipes are electro-polished from the inside.
Working Platform:
A suitable Working Platform is provided to help in the maintenance and operation of the plant.Â
Control Panel:
The electrical control panel houses the necessary electrical components and controls needed to operate the plant. Custom built automation can be incorporated to improve efficiency and reduce errors.
Capacity Available : 500Ltrs. – 15000Ltrs.
